Plexiglass Light-Up Panels (Sign Face Replacements)
Order custom new or replacement panels for your marquee light box or any backlit signage system. These heavy-duty panels are crafted from premium 7328 White Acrylic or Lexan, engineered specifically for optimal backlight diffusion. We face each panel with premium full-color light-up film, printed at double density. This ensures your graphics look rich and saturated during the day, and illuminate brilliantly without washing out at night. [
1,
2]
Note: This product includes the printed plexiglass panel only. The physical light box frame is not included.
Printing & Material Technology
- Double-Density Print: Printed with extra ink layers so colors stay deep during daylight and glow vibrantly when backlit.
- Diffusion Acrylic: Uses industry-standard 7328 White Plexiglass or Lexan to evenly scatter light and eliminate hot spots.
- Full-Color Graphics: High-definition, edge-to-edge printing is included with every panel order.
Shipping & Size Limits
- Shippable Panel Sizes: We safely ship rigid panels up to 36" x 36" or 48" x 24".
- Oversized Panels: We cannot ship rigid panels larger than 36" x 36" or 48" x 24".
- Film-Only Alternative: If you already have a large plastic panel, we can print and ship just the light-up film sticker at any size for you to apply locally.
Material Thickness & Weight Guide
- 0.062" – 0.38 lb/sq ft
- 0.080" – 0.49 lb/sq ft
- 0.093" – 0.56 lb/sq ft
- 0.118" (approx. 1/8") – 0.73 lb/sq ft
- 0.177" (approx. 3/16") – 1.09 lb/sq ft
- 0.236" – 1.46 lb/sq ft
- 0.354" – 2.16 lb/sq ft
- 0.472" – 2.88 lb/sq ft
Product Specifications
- Base Material: 7328 White Acrylic or Shatter-Resistant Lexan
- Graphic Media: Translucent Double-Density Light-Up Film
- Print Style: Full-color single-sided face application
- Maximum Rigid Ship Size: 36" x 36" or 48" x 24"
- Compatibility: Fits standard commercial marquee and outdoor light boxes
| Feature |
Acrylic (Plexiglass) |
Lexan (Polycarbonate) |
| Shatter Resistance |
Moderate |
Virtually Unbreakable |
| Rigidity & Stiffness |
High (Stays flat) |
Lower (More flexible) |
| Scratch Resistance |
Good |
Poor (Scratches easily) |
| UV Lifespan |
Excellent (Resists yellowing) |
Moderate (May yellow over time) |
| Best For |
Standard storefronts, indoor use |
High-vandalism areas, low-hanging signs |
